TROLLEYS





beam trolley



Yale CBTP Trolley

Yale CBT Model -Available in plain and geared models, the CBT is the economical choice for most applications.
The trolley features steel wrap around side plates, dual tread wheels and lifetime lubricated shielded ball bearings.
All the CBTs features combine to ensure you a trolley that is smooth rolling, versatile and reliable.



Product Specs









Chester PTT beam Trolley



Chester PT Trolley

Lifetime lubricated precision ball bearings, in 1/4 through 3 ton capacity trolleys, assure a minimum of manual effort and also of maintenance.

In the 4 ton through 25 ton capacities, each trolley is equipped with eight duo-sealed Timken tapered roller bearings that absorb the radial and thrust loads exerted in these heavier sizes, and reduce manual effort and maintenance to a minimum.

Heavy rolled steel sideplates are shaped to give these trolley units stability and rigidity. They extend beyond the wheels to act as bumpers. Steel equalizing pins connect the two halves of each trolley, providing load equalization and smooth operation.

Trolley wheels are long wearing alloy cast iron. Wheel treads are machined to provide smoothest possible rolling motion. Steel axles are rigidly supported in the side frame. Steel trolley blocks reinforce the side plates as well as the equalizing pin.



Product Specs







If we don't carry it, we'll do our best to find it for you, contact us.
